T - Locked Plate
| SUITABLE FOR |
PROXIMAL TIBIA FRACTURES |
| SCREW |
5.0MM |
| PROFILE |
37.0MM / 17.0MM X 3.0MM |
| DISTANCE BETWEEN HOLE |
16.0MM |
| MATERIAL |
STAINLESS STEEL 316L / 316LVM / TITANIUM |
| HOLES |
2,3,4,5,6,7,8,9,10,11,12 |
| PROXIMAL SCREW |
CANCELLOUS LOCKED SCREW 4.0MM |
| SCREW LENGTH |
20.0MM TO 64.0MM (DIFF. 2.0MM) |
| PROXIMAL / DISTAL SCREW |
CORTEX LOCKING SCREW 5.0MM |
| SCREW LENGTH |
20.0MM TO 64MM (DIFF. 2.0MM) |
| DESCRIPTION |
| HOLE |
CAT. NO. SS. |
CAT. NO. TIT. |
| |
| 02 |
SP05.SS00144 |
SP05.TIT00144 |
| 03 |
SP05.SS00145 |
SP05.TIT00145 |
| 04 |
SP05.SS00146 |
SP05.TIT00146 |
| 05 |
SP05.SS00147 |
SP05.TIT00147 |
| 06 |
SP05.SS00148 |
SP05.TIT00148 |
| 07 |
SP05.SS00149 |
SP05.TIT00149 |
| 08 |
SP05.SS00150 |
SP05.TIT00150 |
| 09 |
SP05.SS00151 |
SP05.TIT00151 |
| 10 |
SP05.SS00152 |
SP05.TIT00152 |
| 11 |
SP05.SS00153 |
SP05.TIT00153 |
| 12 |
SP05.SS00154 |
SP05.TIT00154 |
|
